Unit 4.3a Parallel Computing
Observe an algorithm using parallel computing in Python Code. Monitor processes on host.
- Analyzing Parallel Computing
- Sequential Processing
- Parallel Computing
- Observing Parallel Computing and Threads
- Hacks
Analyzing Parallel Computing
Once again we will use image lab, this time to review Parallel Computing.
- Change baseWidth in this line in code to increase computation requirements:
def process_image(image, baseWidth=512):For instance 320, 512, 1024, 2048, 4096.- Compare Sequential and Parallel computing code and time to achieve outputs
from IPython.display import HTML, display
from pathlib import Path # https://medium.com/@ageitgey/python-3-quick-tip-the-easy-way-to-deal-with-file-paths-on-windows-mac-and-linux-11a072b58d5f
from PIL import Image as pilImage # as PIL Image is used to avoid conflicts
from io import BytesIO
import base64
import numpy as np
# prepares a series of images
def image_data(path=Path("images/"), images=None): # path of static images is defaulted
if images is None: # default image
images = [
{'source': "Internet", 'label': "Green Square", 'file': "green-square-16.png"},
{'source': "Peter Carolin", 'label': "Clouds Impression", 'file': "clouds-impression.png"},
{'source': "Peter Carolin", 'label': "Lassen Volcano", 'file': "lassen-volcano.jpg"}
]
for image in images:
# File to open
image['filename'] = path / image['file'] # file with path
return images
# Scale to baseWidth
def scale_image(img, baseWidth):
scalePercent = (baseWidth/float(img.size[0]))
scaleHeight = int((float(img.size[1])*float(scalePercent)))
scale = (baseWidth, scaleHeight)
return img.resize(scale)
# PIL image converted to base64
def image_to_base64(img, format):
with BytesIO() as buffer:
img.save(buffer, format)
return base64.b64encode(buffer.getvalue()).decode()
# Convert pixels to Grey Scale
def grey_pixel(pixel):
average = (pixel[0] + pixel[1] + pixel[2]) // 3 # average pixel values and use // for integer division
if len(pixel) > 3:
return( (average, average, average, pixel[3]) ) # PNG format
else:
return( (average, average, average) )
# Convert pixels to Red Scale
def red_pixel(pixel):
if len(pixel) > 3:
return( (pixel[0], 0, 0, pixel[3]) ) # PNG format
else:
return( (pixel[0], 0, 0) )
# Convert pixels to Red Scale
def green_pixel(pixel):
if len(pixel) > 3:
return( (0, pixel[1], 0, pixel[3]) ) # PNG format
else:
return( (0, pixel[1], 0) )
# Convert pixels to Red Scale
def blue_pixel(pixel):
if len(pixel) > 3:
return( (0, 0, pixel[2], pixel[3]) ) # PNG format
else:
return( (0, 0, pixel[2]) )
# Set Properties of Image, Scale, and convert to Base64
def image_management(image, baseWidth): # path of static images is defaulted
# Image open return PIL image object
img = pilImage.open(image['filename'])
# Python Image Library operations
image['format'] = img.format
image['mode'] = img.mode
image['size'] = img.size
# Scale the Image
img = scale_image(img, baseWidth)
image['pil'] = img
image['scaled_size'] = img.size
image['numpy'] = np.array(img.getdata())
# Scaled HTML
# Grey HTML
# each pixel in numpy array is turned to grey
# then resulting list, using List Comprehension, is put back into img
img.putdata([grey_pixel(pixel) for pixel in image['numpy']])
# Red HTML
img.putdata([red_pixel(pixel) for pixel in image['numpy']])
# Green HTML
img.putdata([green_pixel(pixel) for pixel in image['numpy']])
# Blue HTML
img.putdata([blue_pixel(pixel) for pixel in image['numpy']])
def process_image(image, baseWidth=2048):
image_management(image, baseWidth)
print("---- meta data -----")
print(image['label'])
print(image['source'])
print(image['format'])
print(image['mode'])
print("Original size: ", image['size'])
print("Scaled size: ", image['scaled_size'])
print("-- images --")
display(HTML(image['html']))
display(HTML(image['html_grey']))
display(HTML(image['html_red']))
display(HTML(image['html_green']))
display(HTML(image['html_blue']))
if __name__ == "__main__":
# setup default images
images = image_data()
# Sequential Processing
for image in images:
process_image(image)
print()
